VFX Variable Frequency Drive

The VFX AC Drive offers reliable, cost-effective, and user-friendly operation of constant torque applications such as crushers, mixers, mills, conveyors, or any other constant torque application that requires accurate and dynamic speed control.

Key Features

  • 3 - 1,500 Amps
  • NEMA enclosure (available in NEMA 1 and NEMA 12 configurations)
  • Unique Shaft Power Load Curve Monitoring and Protection
  • Internal Speed Controller
  • Integrated Vector Braking
  • Sleep function
  • Process language feature, i.e., display GPM
  • Copy function via detachable display unit
  • Smaller footprint than competing VFDs



Looking for an AC Drive solution for Variable Torque applications?



Technical Data

NEMA 12 (IP54) VERSION

Rated Power:        0.75-3,000 kW
Supply Voltage:    230-690V, 3-phase
Rated Current:      2.5-3,000 A
Protection Class:  IP54/NEMA 12
Approvals:            CE, UL, DNV, GOST R

nema 1 (ip20) version

Rated Power:        11-132 kW
Supply Voltage:    230-480V, 3-phase
Rated Current:      25-244 A
Protection Class:  IP20/NEMA 1
Approvals:             Global Standards


product literature


Click here to download product literature for the FDU Variable Frequency Drive.


Click below to view downloadable documents related to this product.


efficient and protective starts and stops

Efficient and protective starts are ensured with Emotron VFX. Reduced start currents, thanks to direct torque control result in smaller fuses, cables, and energy bills. Torque can be boosted to overcome initial peak loads. Integrated vector braking ensures quick and controlled stops, increasing productivity and safety.



Optimized operation and full control

The direct torque control reacts extremely quickly and eliminates disturbances due to abrupt load changes. A built-in load monitor and a unique Load Curve Protection function protect your process by immediately detecting any situation that could cause inefficiency or damage. Early warning and safety stops for over- and underloads allow preventative action.



cost-effective and flexible installation

The compact standalone 2.5 - 250A units are NEMA 12 (IP54) classified. The robust, all-metal construction can be installed close to the application, which eliminates the cost of cabinets and long motor cables.




Simplified maintenance

Should a process problem occur, a full status report will be generated for each event in the fault logger. You can quickly identify the cause and take corrective measures. Maintenance is simplified thanks to a small number of easily accessible mechanical parts and by using fold-out modules in larger units.



User-friendly and reliable operation

Operation parameters can be set in your own process unit - m/sec, tons/hour, cycles, min, etc. - making monitoring easier and more reliable. The removable control panel has a copy function for transferring settings to other VFX units. You can switch between local and remote control with the push of a single key on the control panel. The built-in programmable logical functions, comparators, and timers, means that external PLCs or relays can be avoided in many cases.



Options add Functionality

A number of options let you customize the Emotron VFX 2.0 functionality and fully utilize the product according to your needs. Up to four different options can be combined.


>BUILT FOR PURPOSE The VFX 2.0 is available in either NEMA 1 or NEMA 12 configurations. The robust steel construction of the NEMA 12 version provides the ability to install the drive close to the application, eliminating the cost of cabinets and long motor cables.

>BUILT FOR PURPOSE

The VFX 2.0 is available in either NEMA 1 or NEMA 12 configurations. The robust steel construction of the NEMA 12 version provides the ability to install the drive close to the application, eliminating the cost of cabinets and long motor cables.

>LOAD CURVE MONITORING Built-in load monitoring and unique Load Curve Protection functionality protect your process by immediately detecting any situation that could cause inefficiency or damage. Early warning and safety stops for over- and underloads allow preventative action.

>LOAD CURVE MONITORING

Built-in load monitoring and unique Load Curve Protection functionality protect your process by immediately detecting any situation that could cause inefficiency or damage. Early warning and safety stops for over- and underloads allow preventative action.

>CRANE CONTROL A crane I/O expansion board offers efficient hoist and travel drive and a safety system that activates the mechanical brakes should dangerous loads be detected. Also provides load dependent field weakening functions for hoise drives.

>CRANE CONTROL

A crane I/O expansion board offers efficient hoist and travel drive and a safety system that activates the mechanical brakes should dangerous loads be detected. Also provides load dependent field weakening functions for hoise drives.

>COMM SOFTWARE Communication options include fieldbus communication via Profibus and DeviceNet, Industrial Ethernet communication via Modbus/TCP, EtherCAT and Profinet, and serial communication via RS232 or RS485 with Modbus RTU protocol.

>COMM SOFTWARE

Communication options include fieldbus communication via Profibus and DeviceNet, Industrial Ethernet communication via Modbus/TCP, EtherCAT and Profinet, and serial communication via RS232 or RS485 with Modbus RTU protocol.



40,000

- THE NUMBER OF TIMES PER SECOND THAT DATA IS UPDATED WITH VFX TORQUE CONTROL.

>MOTOR PROTECTION PTC and PT100 sensors can be connected to control motor temperature and give process feedback without using a transmitter.

>MOTOR PROTECTION

PTC and PT100 sensors can be connected to control motor temperature and give process feedback without using a transmitter.

>SAFE STOP This option board offers protection from unexpected start during mechanical maintenance, in accordance to the EN954-1 Category 3 standard. No contactor is required.

>SAFE STOP

This option board offers protection from unexpected start during mechanical maintenance, in accordance to the EN954-1 Category 3 standard. No contactor is required.

>LIQUID COOLING Units from 90A can be provided with liquid cooling. This allows for reduced operating and maintenance costs, and the cabinet can have a protection class higher than IP54/NEMA 12.

>LIQUID COOLING

Units from 90A can be provided with liquid cooling. This allows for reduced operating and maintenance costs, and the cabinet can have a protection class higher than IP54/NEMA 12.



400%

Magnetic Flux and the Torque Estimator make it possible to increase peak torque of Emotron Drives to 400% of nominal torque - even at 0 rpm.

>EMC PROTECTION A 1st environment category 2 EMC filter is available as a factory-mounted option.

>EMC PROTECTION

A 1st environment category 2 EMC filter is available as a factory-mounted option.

>REDUCED HARMONIC DISTORTIONS A 12-pulse rectifier offers a cost-efficient reduction of harmonic current distortions. It reduces power losses in equipment such as transformers and conductors, and eliminates the need to over-size these components.

>REDUCED HARMONIC DISTORTIONS

A 12-pulse rectifier offers a cost-efficient reduction of harmonic current distortions. It reduces power losses in equipment such as transformers and conductors, and eliminates the need to over-size these components.

>STANDBY SUPPLY A standby supply makes it possible to supply the control circuits via an external 24 VAC/DC supply to maintain communication and set up the system when 3-phase mains is not connected. Provides communication backup if 3-phase main power supply fails.

>STANDBY SUPPLY

A standby supply makes it possible to supply the control circuits via an external 24 VAC/DC supply to maintain communication and set up the system when 3-phase mains is not connected. Provides communication backup if 3-phase main power supply fails.



2,100HP

VFX Drives are available for applications thru 2,100HP.

>IP21 TOP COVER If units are wall mounted in an electrical room, a top cover drip protection is available for IP20/NEMA 1 units 11-132 kW.

>IP21 TOP COVER

If units are wall mounted in an electrical room, a top cover drip protection is available for IP20/NEMA 1 units 11-132 kW.

>ENCODER An HTL or TTL encoder can be connected for more accurate speed control or for increased safety through deviation control in crane applications.

>ENCODER

An HTL or TTL encoder can be connected for more accurate speed control or for increased safety through deviation control in crane applications.

>SHORTER BRAKING TIME For short braking time, our continuous braking chopper is available as a factory-installed option. It is used in combination with brake resistor dimensions according to the specific application demand.

>SHORTER BRAKING TIME

For short braking time, our continuous braking chopper is available as a factory-installed option. It is used in combination with brake resistor dimensions according to the specific application demand.


Available in NEMA 1 and NEMA 12 configurations

The Emotron VFX is available in both NEMA 1 (IP20/21) and NEMA 12 (IP54) configurations. The robust steel construction of the NEMA 12 version means that the drive can be installed close to the application, reducing the cost of additional cabinets and motor cables. The 300 - 1,500A units (NEMA 1 modules) are also available in compact CG-designed NEMA 12 cabinets. The 25 - 244A, NEMA 1 series units are optimized for mounting in control cabinets or on an electrical room wall. Its robust yet compact design allows for easy access to power terminals. Extended temperature range up to 130°F (55°C).



vfx Frame Sizes:


Emotron VFX 2.0 Variable Frequency Drive in NEMA 12 / IP54 configuration.

Emotron VFX 2.0 Variable Frequency Drive in NEMA 12 / IP54 configuration.

IP54 version VFX 2.0 Models

Additional models thru 2,100HP available
Emotron VFX 2.0 Variable Frequency Drive in NEMA 1 / IP20 configuration.

Emotron VFX 2.0 Variable Frequency Drive in NEMA 1 / IP20 configuration.

IP20 VERSION VFX 2.0 MODELS

Additional models thru 250HP available

Maximum Power Under Full Control

In 1977, Emotron was the first company to introduce an AC Drive based on Pulse Width Modulation (PWM). Further developments led to one of the first market launches of AC Drives with direct torque control in 1998. The Emotron technology has an extremely fast response time, since actual and required torque is compared 40,000 times per second.

Emotron AC Drives can provide the highest possible torque per ampre from a normal industrial motor, offering the option of controlling a motor without a rotor sensor while still maintaining control of torque and speed.
